Toshiba C70-A Series Maintenance Manual

SatelliteA660/ProA660 Series Maintenance Manual [CONFIDENTIAL] F-1
F.
Appendix F Series Screw Torque List (NWQAA/NWQAE)
Table F-1 Series Screw Torque List
SCREW P/N
SCREW
SPEC
Q'ty LOCATION
SCREW
TORQUE
LCD ASSY
MAAA00153G0 M2.0*3 6
LCD BRK TO LCD
PANEL(R/L)
1.2~1.5kg
MMCK25050G0 M2.5*5 4
LCD BRK L&R to LCD
Cover
2.5~3.0 kg
MMCK25050G0 M2.5*5 4 LCD Bezel to LCD Cover 2.5~3.0 kg
MB
MAA000012G0 M2.0*5 2 Battery connector 2.5~3.0 kg
MAA000012G0 M2.0*5 2 EXP connector 2.5~3.0 kg
MAA000012G0 M2.0*5 2 ODD CONN TO MB 2.5~3.0 kg
MAA000012G0 M2.0*5 2 HDD connector 2.5~3.0 kg
MMCK25050G0 M2.5*5 1 MINI card to MB standoff 2.5~3.0 kg
MAAA00153G0 M2.0*3 2 MDC card to MB standoff 2.5~3.0 kg
AM077000C00
SPRING
SCREW
4
CPU Thermal to CPU
Thermal to mb standoff
standoff
2.5~3.0 kg
MA0000096G0
SPRING
SCREW
3
VGA Thermal to mb
standoff
2.5~3.0 kg
HDD ASSY
MA00000HYG0 M3*3 4 HDD Brk to HDD 2.5~3.0 kg
ODD ASSY
MAAA00153G0 M2*3 2 ODD BRK to ODD 1.2~1.5kg
LOG UP
MA000009KG0 M2.5*6.5 3 Speaker to Up 2.5~3.0 kg
MAA000012G0 M2.0*5 2
TP on/off & Light bar PCB
to Upper
2.5~3.0 kg
MACAJ0602G0 M2.0*2.5 2 FELICA to Upper (BTO) 2.5~3.0 kg
LOGIC ASSY
MMCK25050G0 M2.5*5 6 Hinge Brk to Lower 2.5~3.0 kg
