SatelliteA660/ProA660 Series Maintenance Manual
[CONFIDENTIAL]
F-2
MMCK25050G0 M2.5*5 1 MB TO LOWER 2.5~3.0 kg
MA000005YG0 M2.5*8 2 Low to USB Board to up 2.5~3.0 kg
MAA000012G0 M2.0*5 2 FAN module 2.5~3.0 kg
MAA000012G0 M2.0*5 2 ODD connector 2.5~3.0 kg
MA000005YG0 M2.0*8 2 Low to Up 2.5~3.0 kg
MA000005YG0 M2.5*8 1 Low to KB 2.5~3.0 kg
MA000005YG0 M2.5*8 14 LOWER TO UPPER 2.5~3.0 kg
MA000005YG0 M2.5*8 1 HDD DOOR TO LOWER 2.5~3.0 kg
MA0000035G0 M2.5X5.6 1 RAM door to Low 2.5~3.0 kg
MA000005YG0 M 2.5*8 1 KB support to low 1.2~1.5kg
MACAJ0602G0 M2.0*2.5 1 TP finger to UP 2.5~3.0kg
MA000005YG0 M2.5 *8 1 KB support to MB to Low 2.5~3.0kg
MA000005YG0 M2.5 *8 1 Low to TV tuner to UP 2.5~3.0kg
MA000005YG0 M2.5 *8 2 Low to Mb to KB 2.5~3.0kg
MA000005YG0 M2.5 *8 5 Low to Mb to Up 2.5~3.0kg
MA000005YG0 M2.5 *8 2 Low to Hinge Brk to Up 2.5~3.0kg
MA000005YG0 M2.5 *8 1 Low to Odd brk 2.5~3.0kg
