2 SETTING ITEMS (ADMIN)
94 NETWORK
Checking the network
Two functions are available for checking the network status: ping and traceroute.
The ping function allows you to check the connection status between this equipment and the servers on the network. And,
the traceroute function allows you to view and check the network path to the desired server.
1
On the NETWORK CHECK screen, select the server you want to check, and press
[ping] or [TRACEROUTE].
The check result is displayed.
There are two ways to select the server you want to check.
To select the desired server from the server list displayed on the touch panel:
Checkable servers and supported protocols are as follows.
- Primary DNS server (IPv4/IPv6)
- Secondary DNS server (IPv4/IPv6)
- Primary WINS server (IPv4)
- Secondary WINS server (IPv4)
- SMTP server (IPv4/IPv6)
- POP3 server (IPv4/IPv6)
- Primary SNTP server (IPv4/IPv6)
- Secondary SNTP server (IPv4/IPv6)
- LDAP server 1
- LDAP server 2
- LDAP server 3
- LDAP server 4
- LDAP server 5
- Remote server 1
- Remote server 2
To designate the desired server manually:
Enter the server name, IPv4 address, or IPv6 address manually. When you press the Manual Input field, the on-
screen keyboard is displayed.
For details of the on-screen keyboard, see the following page:
P.154 “On-screen keyboard”
When you have entered a WINS name for the network path of the remote server 1/2 in TopAccess “Save as file
Setting”, you will not be able to perform network check on those servers by selecting them from the server list.
In this case, designate the IP address of the remote server 1/2 manually to perform the network check.
To Next Page
