PREVENTIVE MAINTENANCE (PM)

5 - 35

5.9 Grease List

The parts used for the maintenance of this equipment are as follows.

* : Part list <P-I> represents the page item in "e-STUDIO2820C/2830C/3520C/3530C/4520C Service

Parts List".

5.10 Operational Items in Overhauling

Overhauling must be performed in order to maintain the quality level of this equipment at the following

timing.

e-STUDIO2820C: When the number of output pages has reached 560,000 or 2.5 years have

passed from the start of use (Whichever is earlier.)

e-STUDIO2830C: When the number of output pages has reached 602,000 or 2.5 years have

passed from the start of use (Whichever is earlier.)

e-STUDIO3520C/3530C/4520C:

When the number of output pages has reached 700,000 or 2.5 years have

passed from the start of use (Whichever is earlier.)

(1) Replace all the supplies.

(2) Check the components in the drive section (gears, pulleys, timing belts, etc.). Replace them with

new ones if they are damaged.

(3) Check all the adhesives such as tape and Mylar if they are damaged or have become unstuck.

Replace them with new ones if necessary.

(4) Check the performance of all the switches and sensors. Replace them with new ones if neces-

sary.

(5) Clean inside the equipment thoroughly.

Symbol Grease name Volume Container

Parts list

<P-I>*

L Launa 40 100 cc Oiler 101-21

W1 White grease (Molykote EM-30L) 100 g Tube 101-24

W2 White grease (Molykote HP-300) 100 g Bottle 101-22

W2 White grease (Molykote HP-300) 10 g Bottle 101-22

AV Alvania No.2 100 g Tube 101-23
