2 SETTING ITEMS (ADMIN)
150 IEEE 802.1X Authentication Setting
Setting EAP-MSCHAPv2
1
Select [EAP-MSCHAPv2] and press [Next].
The WIRED 802.1X SETTINGS (EAP-MSCHAPv2) screen is displayed.
2
Specify the following items as required and press [Next].
[EAP-USER NAME] — Press this button to enter the EAP-User name.
[PASSWORD] — Press this button to enter the authentication password.
[RETYPE PASSWORD] — Press this button to re-enter the authentication password.
When you press the above buttons, the on-screen keyboard is displayed. Enter a value using the keyboard and
digital keys, and press [OK] to set the entry.
3
Confirm the settings and press [APPLY NOW].
The “NETWORK INITIALIZING” message is displayed and this equipment starts initializing the network interface
card to apply the changes.
To Next Page
