2.SETTING ITEMS (ADMIN)
Setting Network Functions 121
2 SETTING ITEMS (ADMIN)
4
Continue to another network setting if required, then press [APPLY NOW].
The “NETWORK INITIALIZING” message is displayed and this equipment starts initializing the network interface
card to apply the changes.
IPsec (IP security) setting
When the IPsec Enabler (optional) is adopted, the encrypted communication is enabled using the IPsec (IP Security
Protocol).
The following operations are available in this menu.
y Viewing the IPsec policy name currently applied
y Enabling / Disabling IPsec communication
y Flushing IPsec session
Settings required for IPsec such as entry of IPsec policies can be performed using TopAccess. For details, refer to the
TopAccess Guide.
[IPsec] is available only when the IPsec Enabler (optional) is adopted.
1
Press [NETWORK] in the ADMIN menu.
The NETWORK menu is displayed.
To display the ADMIN menu, see the following page:
P.69 “Entering Admin Menu”
To Next Page
