4.14 Robson card 4 Replacement Procedures
4.14 Robson card
Removing the Robson card
To remove the Robson card, follow the steps below and refer to Figure 4-24.
1. Remove the following screws securing the Robson card.
• M2.0×4B BIND screw ×2
2. Disconnect the Robson card from the connector on the system board.
M2.0x4B BIND
Robson card
Figure 4-24 Removing the Robson card
TECRA A10/S10/P10/SatellitePro S300 Maintenance Manual (960-684) [CONFIDENTIAL] 4-41
