Toshiba TSL3000E Series Interface Manual

– 9 –
INTERFACE MANUAL
STE 85457
Section 1 Type of External Cable
1.1 Layout and Name of Connectors (4-Axis Type/6-Axis Type combined)
The TSL3000E/TSL3100E robot controller is connected with the robot and external
equipment, using connectors and terminal blocks provided on the front and rear
panels of the controller.
Front panel
Fig. 1.1 Layout and name of connectors
②
①
⑨
⑧
⑦
④
⑤
⑩
③
⑥
⑪
⑬
⑫
⑯
⑰
⑱
⑮
⑭
