Toshiba TSL3000E Series Interface Manual

– 46 –
INTERFACE MANUAL
STE 85457
4.8 External Input Signal Cable
4.8.1 Connection of External Input Signal Cable
To connect the external input signal cable, use the attached dummy connector
[XM3A–3721 (plug type connector), XM2S–3711 (connector cover)]. Some system
input signals (normal close contact) of this dummy connector are jumpered.
Remove the jumpers, when necessary.
A cable with its single side soldered to the connector (TSL3000E/TSL3100E: INPUT
cable) is provided optionally. Contact our after-sale service agent in your territory.
