Programming Codes iTherm

280 Programmer’s Guide

28-04430 Rev K Page 97

[ESC] y <12> Disable OCR characters

ASCII [ESC] y <12>

Hexadecimal 1BH 79H 0CH

Decimal <27> <121> <12>

IPCL &%YX012

EPOS [ESC] y <12>

Description The [ESC] y <12> command returns the 30 OCR characters to the

previously selected character set. It does not restore the print mode.

Note: Any character definitions defined by the redefine character set

command are also replaced by the [ESC] y <12> command, documented

in the section Character Attribute Commands
