Specifications and Requirements iTherm

280 Programmer’s Guide

Page 18 Rev K

Physical Characteristics

Dimensions

Max Dimensions

Dimensions in

inches

6.25

8.50

5.87

Weight

Approximate weight: 4.6 lb.

Shipping weight: 6.0 lb.
