TransAct Ithaca 280 - How to Operate the iTherm 280 Printer

Specifications and Requirements iTherm
®
280 Programmer’s Guide
28-04430 Rev K Page 27
Pin Number
Ithaca
®
Epson (Standard)
Star
Signal Name
pin 1 CD2-
pin 2 CD1 Sense
pin 3 Ground
pin 4 CD Drive +(+24V)
pin 5 CD1-
pin 6 Not Connected
Direction
Signal Name
pin 1 Not Connected
pin 2 CD1-
pin 3 CD1 Sense
pin 4 CD Drive + (+24V)
pin 5 CD2-
pin 6 Ground
Direction
Signal Name
pin 1 Not Connected
pin 2 CD1-
pin 3 CD Drive +(+24V)
pin 4 CD Drive +(+24V)
pin 5 CD2-
pin 6 CD1 Sense
Direction
1
Drawer 2 kick out drive
signal
Output
Sink
Drive
Not Connected
Not Connected
2
Drawer 1 open/close signal
Input
Drawer 1 kick out drive
signal
Output
Sink
Drive
Drawer 1 kick out drive
signal
Output
Sink
Drive
3
Signal Ground
Drawer 1 open/close signal
Input
+24V DC
4
+24V DC
+24V DC
+24V DC
5
Drawer 1 kick-out drive
signal
Output
Sink
Drive
Drawer 2 kick out drive
signal
Output
Sink
Drive
Drawer 2 kick out drive
signal
Output
Sink
Drive
6
Not Connected
Signal Ground
Drawer 1 open/close
signal
Input
Table 9 Cash Drawer Pin Assignment
