TransAct Ithaca 280 - Table 36 Automatic Status Back (ASB) Third Byte (Paper Sensor Information); Table 37 Automatic Status Back (ASB) Fourth Byte (Paper Sensor Information); Table 38 Paper Sensor Status (<N> = 1, 49)

Programming Codes iTherm
®
280 Programmer’s Guide
28-04430 Rev K Page 211
Bit
Off/On
Hex
Decimal
Status for Automatic Status Back (ASB)
0
Off
00H
<0>
Journal memory adequate
On
01H
<1>
Journal memory low (Less than 8K)
1
Off
00H
<0>
Paper low sensor: paper adequate
On
02H
<2>
Paper low sensor: paper low
2
Off
00H
<0>
Journal memory adequate
On
04H
<4>
Journal memory exhausted.
3
Off
00H
<0>
Paper out sensor: paper present
On
08H
<8>
Paper out sensor: paper not present
4
Off
00H
<0>
Not used; fixed to Off
5,6
-
-
-
Undefined
7
Off
00H
<0>
Not used; fixed to Off
Table 36 Automatic Status Back (ASB) Third Byte (Paper Sensor Information)
Bit
Off/On
Hex
Decimal
Status for Automatic Status Back (ASB)
0-3
-
-
-
Undefined
4
Off
00H
<0>
Not used; fixed to Off
5,6
-
-
-
Undefined
7
Off
00H
<0>
Not used; fixed to Off
Table 37 Automatic Status Back (ASB) Fourth Byte (Paper Sensor Information)
Function Transmit Status
ASCII [GS] r <n>
Hexadecimal 1DH 72H <n>
Decimal <29> <114> <n>
Range 1  n  2
49  n  50
Description The [GS] r <n> command transmits the status specified by <n> as follows: paper
sensor status as one byte of data when <n> = 1 or 49, and drawer kick-out
connector status when <n> = 2 or 50. The paper present status of bits 2 and 3
for the paper sensor status is not transmitted because the printer goes off line
when a paper out is detected by the paper out sensor. The paper roll low sensor
is an option. If the sensor is not installed, bits 0 and 1 for the paper sensor status
are always in the ―Paper adequate‖ status.
Bit
Off/On
Hex
Decimal
Status
0
Off
00H
<0>
Journal Memory adequate
On
01H
<1>
Journal Memory low (Less than 8K)
1
Off
00H
<0>
Paper low sensor: paper adequate
On
02H
<2>
Paper low sensor: paper low
2
Off
00H
<0>
Journal Memory adequate
On
04H
<4>
Journal Memory exhausted.
3
Off
00H
<0>
Paper out sensor: paper present
On
08H
<8>
Paper out sensor: paper not present
4
Off
00H
<0>
Not used; fixed to Off
5,6
-
-
-
Undefined
7
Off
00H
<0>
Not used; fixed to Off
Table 38 Paper Sensor Status (<n> = 1, 49)
