TransAct Ithaca 280 - Table 32 Print Density Selection; Bit-Image Commands

Programming Codes iTherm
®
280 Programmer’s Guide
Page 208 Rev K
Bit-Image Commands
Function Select Bit-Image Mode
ASCII [ESC] * <m> <nl> <nh> <dl> … <dk>
Hexadecimal 1BH 2AH <m> <nl> <nh> <dl> … <dk>
Decimal <27> <42> <m> <nl> <nh> <dl> … <dk>
Range <m> = 0, 1, 32, 33
0  nl  255
0  nh  3
0  d  255
k = nl + nh x 256 for <m> = 0 or 1
k = (nl + nh x 256) * 3 for <m> = 32 or 33
Description [ESC] * <m> <n
l
> <n
h
> <d
l
> … <d
k
> command selects a bit-image mode using
<m> for the number of dots specified by (n
l
+ n
h
x 256) in mode 0 or 1 and (n
l
+
n
h
x 256)*3 in mode 32 or 33 and <d> indicates the bit image data. Set a bit to
one to print a dot, or set a bit to zero to not print a dot. Use the command to print
a predefined picture or logo. The modes selectable by <m> are listed below.
<m>
Mode
Vertical Direction
Horizontal Direction
Dot Density
Number of
Dots
Dot Density
Number of
Dots
0
8-dot single density
101 dpi
8
80 dpi
200
1
8-dot double density
101 dpi
8
160 dpi
400
32
24 dot single density
101 dpi
24
120 dpi
300
33
24 dot double density
203 dpi
24
240 dpi
600
Table 32 Print Density Selection
