Code 39
Code 39 is an alphanumeric bar code. It is a discrete, self-checking, variable-length code. The
printer prints the complete data field. The number of characters that can be printed depends on
the bar width scaling. If the bar code scale is set to 2, 17 characters may be printed per line.
There are two modes of operation for the Code 39 barcodes. The first is in a variable length
format. In this mode all characters sent to the printer will be printed up to the termination
character. Only 0-9, A-Z -, period, and space may be printed. $, %, +, and / Characters may be
used as escape characters for full 128 character support. If illegal characters are passed to the
printer, they are converted to legal codes. (For example, a would be converted to A).
In full 128 character mode, the printer will encode the full 128 character set. In this mode, the
first character received must be the length. IE. [ESC]k<1><n>… where n specifies the number
of characters to follow. The characters following n characters may be from 0 to 127. Values
greater than 127 are converted to printable characters by removing the 8
th
bit.
The following table specifies the Code 39 character set.
ASCII
Code
NUL
%U
SOH
$A
STX
$B
ETH
$C
EOT
$D
ENQ
$E
ACK
$F
BEL
$G
BS
$H
HT
$I
LF
$J
VT
$K
FF
$L
CR
$M
SO
$N
SI
$O
DLE
$P
DC1
$Q
DC2
$R
DC3
$S
DC4
$T
NAK
$U
SYN
$V
ETB
$W
CAN
$X
EM
$Y
SUB
$Z
ESC
%A
FS
%B
GS
%C
RS
%D
US
%E
ASCII
Code
SP
Space
!
/A
"
/B
#
/C
$
/D
%
/E
&
/F
'
/G
(
/H
)
/I
*
/J
+
/K
,
/L
-
-
.
.
/
/O
0
0
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
:
/Z
;
%F
<
%G
=
%H
>
%I
?
%J
ASCII
Code
@
%V
A
A
B
B
C
C
D
D
E
E
F
F
G
G
H
H
I
I
J
J
K
K
L
L
M
M
N
N
O
O
P
P
Q
Q
R
R
S
S
T
T
U
U
V
V
W
W
X
X
Y
Y
Z
Z
[
%K
\
%L
]
%M
^
%N
_
%O
ASCII
Code
`
%W
a
+A
b
+B
c
+C
d
+D
e
+E
f
+F
g
+G
h
+H
i
+I
j
+J
k
+K
l
+L
m
+M
n
+N
o
+O
p
+P
q
+Q
r
+R
s
+S
t
+T
u
+U
v
+V
w
+W
x
+X
y
+Y
z
+Z
{
%P
|
%Q
}
%R
~
%S
DEL
%T
Figure 7 Code 39 full 128 character encoding
Code 128
Code 128 is an alphanumeric bar code. It is a high-density, variable-length, continuous code,
which employs multiple element widths. Code 128 has three possible start codes. The start
