Programming Codes iTherm
®
280 Programmer’s Guide
Page 212 Rev K
Bit
Off/On
Hex
Decimal
Status
0
Off
00H
<0>
Drawer kick-out connector pin 3 low
On
01H
<1>
Drawer kick-out connector pin 3 high
1-3
-
-
-
Undefined
4
Off
00H
<0>
Not used; fixed to Off
5,6
-
-
-
Undefined
7
Off
00H
<0>
Not used; fixed to Off
Table 39 Drawer Kick-out Connector Status (<n> = 2, 50)
Function Transmit Real-Time Status
ASCII [DLE] [EOT] <n>
Hexadecimal 10H 04H <n>
Decimal <16> <4> <n>
Range 1  n  4
Description The [DLE] EOT <n> command transmits the specified status in real time. The
command is executed if the printer is off line, the print buffer is full, or an error
occurs. If the printer goes off line due to a paper-end condition, bit 5 of the
printer status (waiting for on-line recovery) is on from the time the paper roll is
inserted to the time the printer goes on-line. See the [GS] z 0 command for
details of the on-line recovery wait time. The paper roll low sensor is an option.
If the printer does not have a paper low sensor, bits 2 and 3 of the paper roll
sensor status will always be ―Paper adequate.‖ Bit 3 of the second byte is always
―No error occurred.‖
<n>
Function
1
Transmit printer status
2
Transmit off line status
3
Transmit error status
4
Transmit paper roll sensor status
Table 40 Values for the Status Function, <n>
Bit
Off/On
Hexl
Decimal
Status
0
Off
00H
<0>
Not used; fixed to off
1
On
02H
<2>
Not used; fixed to on
2
Off
00H
<0>
Drawer kick-out connector pin 3 low
On
04H
<4>
Drawer kick out connector pin 3 high
3
Off
00H
<0>
On-line
On
08H
<8>
Off line
4
On
10H
<16>
Not used; fixed to on
5
-
-
-
Undefined
6
-
-
-
Undefined
7
Off
00H
<0>
Not used; fixed to off
Table 41 Printer Status (<n> = 1)
