Programming Codes iTherm

280 Programmer’s Guide

Page 104 Rev K

[ESC] % G Begin italics

ASCII [ESC] % G

Hexadecimal 1BH 25H 47H

Decimal <27> <37> <71>

IPCL &%MI

EPOS [ESC] 4

Description The [ESC] % G command begins italic print mode.

Note: Italics are not available in all print modes.

[ESC] % H End italics

ASCII [ESC] % H

Hexadecimal 1BH 25H 48H

Decimal <27> <37> <72>

IPCL &%CI

EPOS [ESC] 5

Description The [ESC] % H command ends italic print mode.
