Programming Codes iTherm
®
280 Programmer’s Guide
28-04430 Rev K Page 163
[ESC] p 4 Select paper sensor(s) to stop printing
ASCII [ESC] p 4 <n>
Hexadecimal 1BH 70H 34H <n>
Decimal <27> <112> <52> <n>
Range 0 n 255
Description The [ESC] p 4 <n> command selects the sensors that tell the printer to
stop printing. The default setting occurs when only the Paper Out sensor
stops printing. When the paper roll near-end sensor is enabled and the
sensor detects a near-end condition during printing, the printer completes
the current line and then automatically goes off-line. Replacing a new
paper roll restarts the printing. When the paper roll near-end sensor is
disabled and a paper near-end condition is detected during printing, the
paper out LED comes on, but the printer continues to print.
Note: The ITherm
®
does not allow the Paper Out sensor to be disabled. It
is always on.
<n> is defined as follows:
Paper roll near-end sensor disabled
Paper roll near-end sensor enabled
Table 19 Paper Sensor Commands
[ESC] p 3 Select paper sensor(s) to output paper-end signals
ASCII [ESC] p 3 <n>
Hexadecimal 1BH 70H 33H <n>
Decimal <27> <112> <51> <n>
Range 0 n 255
Description The [ESC] p 3 <n> command selects the paper sensor that outputs a
paper-end signal to the parallel interface when a paper-end is detected.
The default setting is when all sensors are enabled. (<n> = 15). It is
possible to select multiple sensors to output signals. If any of the sensors
detect a paper end, the paper end signal is output. The command is only
available with a parallel interface. The paper-end sensor is an option. If
the sensor is not equipped, the settings of bits 0 and 1 of the command
are not effective.
