TransAct Ithaca 280 - Page 236

Programming Codes iTherm
®
280 Programmer’s Guide
Page 224 Rev K
Function Generate Pulse
ASCII [ESC] p <m> <t
1
> <t
2
>
Hexadecimal 1BH 70H <m> <t
1
> <t
2
>
Decimal <27> <112> <m> <t
1
> <t
2
>
Range <m> = 0, 1, 48, 49
0  t1  255
0  t2  255
Description The [ESC] p <m> <t
1
> <t
2
> command sends a pulse (on time = <t
1
> x 2 msec) to
the specified connector pin. When <m> = 1 or 48, the pulse is sent to drawer-
kick-out connector pin 2. When <m> = 0 or 48, the pulse is sent to drawer-kick-
out connector pin 2; when <m> = 1 or 49, the pulse is sent to drawer-kick-out
connector pin 5.
Function Generate Pulse in real time
ASCII [DLE] [DC4] <1> <m> <t>
Hexadecimal 10H 14H <1> <m> <t>
Decimal <16> <20> <1> <m> <t>
Range 0  m  8
0  t  8
Description The [DLE] [DC4] <1> <m> <t> command sends a pulse specified by <t> in real-
time to the connector pin specified by <m> as follows:
<m>
Connector pin
0
Drawer kick-out connector pin 2
1
Drawer kick-out pin 5
Note: This feature is licensed from Epson, and is only available in the Full
Epson Emulation of the firmware. Problems with this command are
frequently caused by not using the correct version of the firmware.
Contact Transact sales and/or technical support for this added cost option.
Function Execute power-off sequence
ASCII [DLE] [DC4] <2> <a> <b>
Hexadecimal 10H 14H <2> <a> <b>
Decimal <16> <20> <2> <a> <b>
Range a = 1
b = 8
Description The [DLE] [DC4] <2> <a> <b> command executes the printer power-off
sequence as follows:
Stores the values of the maintenance counter.
Transmits the following power-off status (Header + Status + NUL)
Power off status
Hex
Decimal
Amount of data
Header
3BH
59
1 byte
Status
30H
48
1 byte
NUL
00H
0
1 byte
Executes the printer power off
