TransAct Ithaca 280

To Next Page

To Previous Page

Programming Codes iTherm

280 Programmer’s Guide

Page 84 Rev K

m/203 (m/8) Dot Width

n/203 (n/8)

Cut to Center of black dot

Back of Ticket

0.8 (.20) to first line of print

Dimensions in Inches (mm)

Note: This command interacts with the Feed to Black Dot command. If

the Black Dot paper Option is set, the black dot position specified by this

command will be used for the Cover Close operation.
