Maintenance and repair
Replacing the conveyor belt
68
Operating instructions: Indexing conveyor/short track conveyor TS 1300
Version 3.6ENG, 28.02.2019
2. Check that the belt edge lug (2) is correctly positioned between the ball
bearings in the holders.
3. Turn the locking lever to "Close".
The upper belt edge holder parts have been assembled - lower run.
Assemble the cross
beams, only for BN >
1200 mm
Complete the following steps:
Assembly must be carried out in the reverse order.
The cross beams have been assembled, only for BN > 1200 mm.
Assemble the bed
Complete the following steps:
Assembly must be carried out in the reverse order.
The bed has been fitted.
