B. Modes of Operation
C. Filter Settings
To record instantaneous ow: set the ow
output [Filter] to a frequency at least 10
times the rate of ow pulsation. The digital
sample rate for data recording should be
set to a minimum of 3 times the application
frequency.
D. Analog Outputs
Transonic
®
Flow Modules output analog signals in the range of -5 volts to +5 volts that are compatible
with most A/D (analog-to-digital) converters of Data Acquisition Systems. The back panel analog outputs
generated by the TS410 Module are listed in the table below:
TS410 Module: Functions & Controls
NUMBER TERMINAL NAME VOLTAGE DESCRIPTION
12 Sync In In/Out required for operation; Multi-Module synchronization
11 Sync Out In/Out required for operation; Multi-Module synchronization
10 GND Ground
9 GND Ground
8 Rec Amp 1 0 - 4 V Quality of ultrasound transmission for testing Sensor functionality, acoustic coupling
or blockage of ultrasound by air or other impedance mismatch. Can be used in bubble
detection by indicating a drop in signal as air passes through the Flowsensor. 2 V = 100%
7 Rec Amp 2 0 - 4 V Same as Rec Amp 1 for the second pair of transducers. 2 V = 100%
6 Phase 2 B ± 5 V Same as Phase 2 A but offset by +4.5 V or -4.5 V
5 Phase 2 A ± 5 V Same as Phase 1 A but for the second pair of transducers
4 Phase 1 B ± 5 V Same as Phase 1 A but offset by +4.5 V or -4.5 V
3 Phase 1 A ± 5 V Acoustic velocity of uid used in ultrasound indicator dilution studies
2 Mean Flow ± 5 V Average volume ow output, ltered at 0.1 Hz
1 Puls Flow ± 5 V Instantaneous pulsatile volume ow output, ltered at 10, 40, or 160 Hz depending on the
Module front panel [Filter] setting. Output defaults to 160 Hz if 0.1 Hz button depressed.
All PXN and PXL Sensors have two pairs of transducers. Flow data is determined from the combination of both pairs while phase and
received amplitude data are separated by transducer pair.
HEART RATE OR
APPLICATION FREQUENCY
LOW PASS
FILTER
SETTING
RECOMMENDED MINIMUM
DIGITAL SAMPLE RATE FOR
DATA ACQUISITION
Average Flow Recording 0.1 Hz 0.3 Hz
Pulsatile to 60 beats/minute 10 Hz 30 Hz
Pulsatile to 240 beats/minute 40 Hz 120 Hz
Pulsatile to 960 beats/minute 160 Hz 500 Hz
MODE
OUTPUTS
LCD DISPLAY
Front Bottom
LED DISPLAY
Front Top
MEAN & PULSATILE FLOW
Front BNC/ Rear Analog
MEASURE Flowsensor model & serial number Bar indicator of signal quality
Average ow in mL/min or L/min
Start-up & error messages
Flow = recorded voltage x scale factor
Bidirectional ow output ± 5 V
SENSOR STATUS
Flowsensor calibration parameters: Fluid
type, temperature, tubing type, tubing
dimensions & % gain if adjusted
METER STATUS
Module settings: Invert ow status, 1/4
scale status & active alarm values
MENU: SENSOR CONTROLS Select & change calibration & gain
MENU: METER CONTROLS
Alarm setup
1/4 ow scale Increase ow resolution Scale factor reduced by 1/4
Invert Change sign of ow Reverse signal polarity
Calibrate 0 volt scale 0 mL/min 0 V = 0 mL/min
Calibrate 1 volt scale Scale factor ow value 1 V = scale factor ow
