40 Installation (for qualified installers only)
© Travis Industries 3/13/18 - 1474 42 & 54PB GSB2 Aust.
Screen Assembly Mounts
The screen assembly mounts (located on outer front edges of the fireplace) are adjustable to allow the screen
assembly to be positioned 1/2" (13mm) to 1-/12” (38mm) from the front of the fireplace. This allows facing to tuck
under the screen assembly. Each mount is held in place by (3) Philips head screws. Before mounting the screen
assembly, adjust the mounts so that the front edge is flush with the finish material surrounding the fireplace. To
adjust the mounts, loosen the screws, slide the mounts to the desired position, then tighten the screws.
Position edge of mount
flush with finish material
To Next Page
