Installation (for qualified installers only) 41
© Travis Industries 3/13/18 - 1474 42 & 54PB GSB2 Aust.
Do Not Drill or Screw Zone
When using screws to secure tile-board or other non-combustible to the front of the fireplace, make sure to avoid
the area on the front of the fireplace that is painted with the “DO NOT DRILL” shading. Make sure screws
penetrate no more than ½” (13mm) into the fireplace.
Do not drill or screw in
the marked area
To Next Page
