TEW-455APBO High Power Wireless Outdoor PoE Access Point
56
Chapter 4. WDS Mode Configuration
Please refer to illustrations of the section 1.3 for possible applications in the WDS mode. This section provides
detailed explanation for users to configure in the WDS mode with help of illustrations. In the WDS mode,
functions listed in the table below are also available from the Web-based GUI interface.
Table 4-1: WDS Mode Functions
4.1 External Network Connection
4.1.1 Network Requirement
You could expand your Ethernet network via WDS link. In this mode, the TEW-455APBO connects directly to a
wired LAN, and wirelessly bridges to a remote access point via a WDS link as shown in Figure 4-1. In the mode,
it can’t associate with any wireless clients.
Figure 4-1 Point to Point Configuration
