TEW-455APBO High Power Wireless Outdoor PoE Access Point
73
While creating multiple Virtual Server rules, the prior rules have higher priority. The Virtual server rules have
precedence over the DMZ one while both rules exist. Example 1 and 2 demonstrate proper usage of DMZ and
Virtual Server rules.
 Example 1 : All connections should be redirected to 192.168.2.12 while DMZ is enabled. Since Virtual
Server rules have precedence over the DMZ rule all connections to TCP port 22 will be directed to TCP
port 22 of 192.168.2.10 and remaining connections to port TCP 20~80 will be redirected to port TCP
20~80 of 192.168.2.11
DMZ Enabled : 192.168.2.12
Rule
Protocol
Private IP
Private Port
Public Port
1
TCP
192.168.2.10
22
22
2
TCP
192.168.2.11
20:80
20:80
 Example 2 : All connections should be redirected to 192.168.2.12 while DMZ is enabled. Since Virtual
Server rules have precedence over the DMZ rule all other connections to TCP port 20~80 will be
redirected to port 20~80 of 192.168.2.11. The rule 2 won’t take effect.
DMZ Enabled : 192.168.2.12
Rule
Protocol
Private IP
Private Port
Public Port
1
TCP
192.168.2.11
20:80
20:80
2
TCP
192.168.2.10
22
22
