©Copyright2017TRENDnet.AllRightsReserved.
TRENDnetUser’sGuide
TEW‐825DAP
16
o Aonly:Thismodeonlyallowsdevicestoconnecttotheaccesspointusingolder
andslower802.11atechnology(typicallynotrecommended).
o A/Nmixed:Thismodeonlyallowsdevicestoconnecttotheaccesspointusing
olderandslower802.11aor802.11ntechnologyandittherebyreducesthe
accesspoint’smaximumspeedto54Mbps(typicallynotrecommended).
o Nonly:Thismodeonlyallowsnewer802.11ndevicestoconnecttoyouraccess
point.Thismodedoesensurethehighestspeedandsecurityforyournetwork,
however,ifyouhaveolder802.11awirelessclients,theywillnolongerbeableto
connecttothisrouter.
o N/ACmixed:Selectthismodeforthebestcompatibility.Thismodeallowsolder
802.11awirelessdevicestoconnecttotheaccesspointinadditiontonewer
802.11acdevices.
o AConly:Thismodeonlyallowsdevicestoconnecttotheaccesspointusing
newerandfaster802.11actechnology(typicallynotrecommended).
o A/N/ACmixed:Selectthismodeforthebestcompatibility.Thismodeallows
older802.11aand802.11nwirelessdevicestoconnecttotheaccesspointin
additiontonewer802.11acdevices.
Note:Pleasecheckthespecificationsonyourwirelessdevicesforthehighest
wirelesscapabilitysupportedfirstbeforeapplyingthesesettings.Ifyouare
unsure,itisrecommendedthatyoukeepthedefaultsetting(A/N/ACmixed)for
thebestcompatibility.
Whenapplyingthe802.11modesetting,pleasekeepinmindthefollowing:
Wirelessdevicesthatsupport802.11narebackwardscompatibleandcan
connectwirelesslyat802.11gor802.11b.
Connectingat802.11bor802.11gwilllimitthecapabilityofyour802.11n
supportedwirelessdevicesfromobtaininghigherperformanceanddatarates.
Allowing802.11bor802.11gdevicestoconnecttoan802.11ncapablewireless
networkmaydegradethewirelessnetworkperformancebelowthehigher
performanceanddataratesof802.11n.
Wirelessdevicesthatonlysupport802.11bor802.11gwillnotbeableto
connecttoawirelessnetworkthatissetto802.11nonlymode.
Wirelessdevicesthatonlysupport802.11bwillnotbeabletoconnecttoa
wirelessnetworkthatissetto802.11gonlymode.
ChannelWidth:Selectthechannelwidthfortheaccesspointtooperateon.By
default,theaccesspointisonAuto20/40MHz.
Extensionchannel:When20/40channelbandwidthhasbeenchosen,youshould
selectextensionchanneltogethigherthroughput.
Frequency(Channel):InNorthAmerica,thisroutercanbroadcaston1of11
Channelsfor2.4GHz(13inEuropeandothercountries).SelectingtheAutooption
enablestheroutertoautomaticallyselectthebestChannelforwireless
communication.Tomanuallysetthechannelonwhichtherouterwillbroadcast,
clickthedrop‐downlistandselectthedesiredChannelforwirelesscommunication.
ThegoalistoselecttheChannelthatisleastusedbyneighboringwireless
networks.
WirelessProfile
Wireless(2.4GHzor5GHz)>WirelessNetwork
Thissectionoutlinestheavailablefeaturestoconfigureforbothwireless2.4Ghzand
5GHzwhenAccessPointmodeisselected.
1.Logintoyourmanagementpage(see“Accessthemanagementpage”onpage16).
2.ClickonthewirelessbandyouwouldliketoconfigureandclickWirelessNetwork.
3.Underneaththebasicwirelessbandsection,youwillseeWirelessNetworkandall
yourwirelessnetworkprofileswillbelisted.
4.ClickontheEditbuttonnexttothewirelessprofileyouwanttoconfigure.
5.Reviewthewirelesssettings,clickApplyandSave/Reloadwhenfinished.
