TEW‐825DAP
3
Reset
button
FrontView






 Gigabitport:PluganEthernetcable(alsocallednetworkcables)from
youraccesspointtoyourrouterandwirednetworkdevices
.
 Powerport:Connectthepoweradapterfromyouraccesspointpowerportto
anavailablepoweroutlet.
 Resetbutton:Useasharptooltopressandholdthisbuttonfor10secondsto
resettheaccesspoint.






ApplicationDiagram

Theaccesspointprovidesconcurrent1300MbpsandWiFiACand450MbpsWiFiNcombined
withAP,Client,WDSandRepeatermodessupportmultipleapplications.


Connectwirelessdevicestoyouraccesspoint
Avarietyofwirelessnetworkdevicescanconnecttoyourwirelessnetworksuchas:
 WirelessLaptopcomputers
 Networkmediaplayers
 WirelessIPcameras
 SmartPhones
 GamingConsoles
 InternetenabledTVs

Eachdevicemayhaveitsownsoftwareutilityforsearchingandconnectingtoavailable
wirelessnetworks,therefore,youmustrefertotheUser’sManual/Guideofyour
wirelessclientdevicetodeterminehowtosearchandconnecttothisrouter’swireless
network.
Seethe“Appendix”onpage53forgeneralinformationonconnectingtoawireless
network.
GigabitPort
Powerport
