12
Model Three - Operation Manual
Auto Test Programs
The Model Three can be set to automatically perform QAM, Level,
Spectrum, Tilt (Favorite), Hum, and Limit tests in user settable time
increments. This makes the Model Three ideal for performing required
24-hour tests. The test result files can be viewed or uploaded to a PC
later.
Voltmeter
The Model Three is equipped with a built-in voltmeter that can be used
for troubleshooting power supplies or power drops. The Model Three
displays the voltage with a bar graph and numeric readout. It can
accommodate AC or DC voltages up to 100 Volts.
File Saving and Viewing
The Model Three can save records from QAM, Level, Tilt (Favorite
channels group), Spectrum, Hum, Scan, or Limit test measurements
either to individual files or all to one file. These files can be recalled to
display the recorded data, and Scan, Spectrum, and Limit graphics
can be viewed. All files may be uploaded to a PC with the Model
Three ToolBox software for analysis, storage, and printing.
Equipment Supplied with Your Model Three
The Model Three comes with the following:
• Model Three signal level meter
• Protective carrying case
• Strap for carrying case
• Blue rubber protective bumper
• 11.1 V / 1.4 AH Li-Ion battery
• AC to DC power adapter and battery charger
• Operation manual on CD
