57
Model Three - Operation Manual
The Maximum Δ Video and Maximum Δ Adjacent channel status are
determined by the results of the overall channel plan measurements. Press
the
F
2
and
F
3
keys to view the Minimum and Maximum Video
channels and levels. Also, if a failure has occurred for the Maximum Δ
Adjacent channel test, the adjacent channels with the greatest variation
are listed.
The Minimum Video, Maximum Video, Minimum Δ V/A, and Maximum Δ
V/A are tested for all channels in the User Plan. If any channel fails one of
these tests, the Test Result summary indicates a failure X for that test. If
all channels pass one of these tests, the Test Result summary indicates a
pass (check mark) for that test.
A digital (DIGI) type channel is measured
during the Limit test but is not used to
determine Pass or Fail for any of the tests.
