2.9 Map Window
SkyLink's map displays the location of the gimbal, it's line of sight, and sensor footprint. It also
displays and manages 3D terrain data and imagery. The coordinates and altitude of the cursor will
be displayed in the bottom of the window. The map can be set to different follow modes by clicking
on the follow menu for following:
• “Follow Gimbal” (default) the map will keep the gimbal's location centered on the map.
• “Follow Heading” the map will keep the gimbal heading pointed up and center the gimbal on
the map.
• “Follow Image” the map will keep the center of the sensor footprint centered on the map.
• “Follow None” the map will say stationary where the user pans.
