Trillium User Guide Trillium Engineering Page 60
Pin Number
Signal
Level
Direction
Description
1
GND
Ground – Input Power Return
19
ETH_TX+
OUT
Ethernet 10/100 (Coms/Digital Video)
36
ETH RX+
IN
Ethernet 10/100 (Coms/Digital Video)
2
GND
Ground – Input Power Return
20
ETH_TX-
OUT
Ethernet 10/100 (Coms/Digital Video)
37
ETH_RX-
IN
Ethernet 10/100 (Coms/Digital Video)
3
GND
Ground – Input Power Return
21
GND
Ground – Input Power Return
38
Reserved
RESERVED FOR FUTURE USE
4
GND
Ground – Input Power Return
22
GND
Ground – Input Power Return
39
Reserved
RESERVED FOR FUTURE USE
5
POWER
10-30V
IN
Input Power
23
GND
Ground – Input Power Return
40
Reserved
RESERVED FOR FUTURE USE
6
POWER
10-30V
IN
Input Power
24
GND
Ground – Input Power Return
41
POWER
10-30V
IN
Input Power
7
POWER
10-30V
IN
Input Power
25
POWER
10-30V
IN
Input Power
42
SERIAL 1 TX
5V RS232
OUT
Auxiliary Serial Communication
8
POWER
10-30V
IN
Input Power
26
POWER
10-30V
IN
Input Power
43
GND
Ground
9
POWER
10-30V
IN
Input Power
27
Reserved
RESERVED FOR FUTURE USE
44
Reserved PWM1
RESERVED FOR FUTURE USE
10
Reserved
RESERVED FOR FUTURE USE
28
GND
Ground
45
SERIAL 1 RX
5V RS232
IN
Auxiliary Serial Communication
11
Reserved
RESERVED FOR FUTURE USE
29
SERIAL 2 RX
5V RS232
IN
Auxiliary Serial Communication
46
SERIAL 2 TX
5V RS232
OUT
Auxiliary Serial Communication
12
Reserved
RESERVED FOR FUTURE USE
30
SERIAL 4 TX
3.3V TTL
OUT
Auxiliary Serial Communication
47
Reserved
RESERVED FOR FUTURE USE
13
Reserved
RESERVED FOR FUTURE USE
31
GND
Ground
48
Reserved
RESERVED FOR FUTURE USE
14
SERIAL 0 TX
5V RS232
OUT
Primary Serial Communication
32
SERIAL 4 RX
3.3V TTL
IN
Auxiliary Serial Communication
49
Reserved
RESERVED FOR FUTURE USE
15
GND
Ground
33
Reserved
INTERNAL USE ONLY
50
Reserved
RESERVED FOR FUTURE USE
16
SERIAL 0 RX
5V RS232
IN
Primary Serial Communication
34
GND
Ground
51
POWER ENABLE
3.3V
IN
Open, Tri-state or 3.3V: RUN
(Power ON)
GND: OFF (Power Down)
17
ANALOG VIDEO
OUT
1V p-p
OUT
NTSC Analog Video Out
35
Reserved
INTERNAL USE ONLY
18
GND
Ground - Analog Video RTN
