Trimble TMX-2050 - Connecting the Display Only

2
TRIMBLE TMX-2050 DISPLAY CABLING GUIDE
13
CHAPTER
Connecting the Display Only 2
In this chapter:
 Manual guidance using SBAS, OmniSTAR
HP/G2, or RTX corrections
 Manual guidance using radio and RTK
corrections
 Manual guidance using CenterPoint VRS or
VRSNow corrections
 Manual guidance using a modem and RTK
corrections
The TMX-2050 display can operate as a
standalone guidance system, or you can connect
it to a range of agricultural guidance devices to
expand its functionality.
Use Trimble cables only. Trimble cables use
specific wire gauges not found in some
off-the-shelf RJ45/CAT 6 cables.
To connect the display:
• as a standalone guidance system, see
Chapter 2.
• to the EZ-Steer assisted steering or EZ-Pilot
steering system, see Chapter 3
• to the Autopilot automated steering system,
see Chapter 4.
• to a Field-IQ control system, see Chapter 5.
