Trimble TMX-2050 Cabling Guide

TRIMBLE TMX-2050 DISPLAY CABLING GUIDE
1 – Components and Cable Configuration Guidelines
9
AG-815 integrated radio
The AG-815 integrated radio is required for using RTK connections.
Item Description
❶ Optional GNSS connector for future use
❷ Radio antenna connector
❸ Expansion slot connector for connection to the TM-200 Module
❶
❷
❸
TM-200 Module
AG-815 radio
❶
❷
