TRIMBLE TMX-2050 DISPLAY CABLING GUIDE
19
CHAPTER
Connecting to the EZ-Steer /
EZ-Pilot System 3
In this chapter:
 EZ-Steer system using SBAS / RangePoint RTX
/ CenterPoint RTX / OmniSTAR HP|G2
corrections
 EZ-Steer system using SBAS / RangePoint RTX
/ CenterPoint RTX / OmniSTAR corrections
with external power leads
 EZ-Pilot steering system
This chapter describes how to connect the
TMX-2050 display to the Trimble EZ-Steer
assisted steering system or the Trimble EZ-Pilot
steering system.
Use Trimble cables only. Trimble cables use
specific wire gauges not found in some
off-the-shelf RJ45/CAT 6 cables.
