TRIMBLE TMX-2050 DISPLAY CABLING GUIDE
34
CHAPTER
Connecting the Field-IQ Crop Input
Control Systems 5
In this chapter:
 Field-IQ Rate and Section Control cab kit/
Autopilot system
 Field-IQ Rate and Section Control cab kit /
EZ-Pilot system
 Field-IQ Rate and Section Control cab kit /
EZ-Steer system
 Field-IQ Rate and Section Control cab kit/
Sprayer full platform kit
 Field-IQ Boom Height Control and Field-IQ
Rate and Section Control
 Field-IQ Boom Height Control and Field-IQ
Rate and Section Control / Autopilot system
 Field-IQ Section Control to Raven 4x0 rate
control
 Field-IQ Rate and Section Control to
EZ-Boom harness
 Field-IQ Section Control to Raven 4x00 rate
control
This chapter shows the different ways to
connect the TMX-2050 display to the Field-IQ
™
crop input control system.
Use Trimble cables only. Trimble cables use
specific wire gauges not found in some
off-the-shelf RJ45/CAT 6 cables.
C
CAUTION – Connecting the port
replicator on the TM-200 to
NavController II cable to the P4 or P12
connector of the NavController II harness
will result in damage to the TMX-2050
display, and will void the warranty.
