4
TRIMBLE TMX-2050 DISPLAY CABLING GUIDE
25
CHAPTER
Connecting to the Autopilot System4
In this chapter:
Autopilot system using SBAS / OmniSTAR /
RTX corrections
Autopilot system using RTK corrections
Autopilot system using RTK corrections on a
factory-ready CNH vehicle
Autopilot system using VRS corrections with
a DCM-300 modem
This chapter shows the different ways to
connect the TMX-2050 display to the
Autopilot™ automated steering system.
Use Trimble cables only. Trimble cables use
specific wire gauges not found in some
off-the-shelf RJ45/CAT 6 cables.
C
CAUTION – Connecting the Port
Replicator of the NavController II cable to
the P4 or P12 connector of the
NavController II harness will result in
damage to the equipment, and will void
the warranty.
