TRIMBLE TMX-2050 DISPLAY CABLING GUIDE
4 – Connecting to the Autopilot System
33
❽ DCM-300 cellular antenna 72122
DCM-300 cellular antenna 51227
❾ DCM-300 cellular modem 80632-xx
❿ DCM-300 modem to TM-200 Module to power cable 94267
⓫ WiFi antenna 83700-05
⓬ TM-200 Module (port A) to NavController II cable with port replicator 75741
⓭ 2-pin DTM to 2-pin DT power adaptor 67095
⓮ Main NavController II harness 54601
⓯ NavController II 55563-00
Item Description Trimble part number
