TRIMBLE TMX-2050 DISPLAY CABLING GUIDE
5 – Connecting the Field-IQ Crop Input Control Systems
38
⓯ TM-200 Module to Field-IQ cable 75834
⓰ Steering Sensor Extension cable and Field-IQ Switch Box Extension 55656
⓱ Field-IQ master switch box 75050-01
⓲ 12-section switch box (optional) 75060-01
Item Description Trimble part number
To Next Page
