TRIMBLE TMX-2050 DISPLAY CABLING GUIDE
5 – Connecting the Field-IQ Crop Input Control Systems
46
Item Description Trimble part number
❶ TMX-2050 display 96700-00
❷ TM-200 Module to display cable 93843
❸ TM-200 Module 95060-00
❹ TM-200 Module power and I/O cable connected to port B 92676
❺ TM-200 Module battery cable 92905
❻ AG-25 GNSS antenna to TM-200 Module cable 50449
❼ AG-25 GNSS antenna 77038-01
❽ TM-200 Module to Field-IQ cable 75834
❾ Field-IQ master switch box 75050-01
❿ Signal Input Module - SIM 76774-00
⓫ Switch Input Cable
⓬ Rate and section control module 75774-00
⓭ Field-IQ sprayer cab cable 80099
⓮ To Sprayer wet works and power
⓯ Emergency stop cable 90528
⓰ Field-IQ cab to hitch cable 77368
⓱ Field-IQ dual relay power disconnect cable 77533
⓲ Field-IQ power cable 76941
⓳
Field-IQ CAN/power extension 75528-xx
⓴ VM430 valve module 80585-00
w
Field-IQ cab to hitch cable 90541-xx
x
VM430 valve module tee cable 90569
y
VM430 to valve cable 86855
z
Boom height control power Y cable 90531
A
Boom Height Control power /CAN cable 90513
B
Boom Height Control power / CAN extension cable 86592-xx
C
Boom Height Control terminator adaptor 86594
D
Boom Height Control SS-100 sensor 88473-00
E
NavController II 55563-00
F
Main NavController II harness 54601
G
2-pin DTM to 2-pin DT power adapter 67095
H
TMX-2050 power adapter 94645
