Troxler 4140 User Manual

Model 4140
2-23
************************************************
TROXLER 4140 Gyratory Compactor
SN: 107
Date: 5/24/96 Time: 2:13PM
************************************************
GYRATORY COMPACTOR SAMPLE INFORMATION
************************************************
Project Number 11166677C
Maximum Specific Gravity, Gmm 2.200
Gyrations: N initial = 6 N Design = 54 N Maximum = 80
Mix Design Number 44444
Actual Asphalt Content
Vertical Consolidation Pressure 200 KPa
Sample Weight
5075g.
Gmb 2.550
Date: 2/15/96
Time:
3:45 pm
Sample 1
Height
Gmb(est)
Gmb(corr)
%Gmm
N ini
128.1
2.242
2.263
86.9
N des
115.2
2.493
2.517
96.7
N max
113.7
2.526
2.550
97.9
Sample Weight
3:07 pm
5021g. Gmb 2.548 Date: 2/15/96 Time:
Sample 2
Height
Gmb(est)
Gmb(corr)
%Gmm
N ini
125.1
2.271
2.283
87.7
N des
113.5
2.503
2.517
96.7
N max
112.1
2.534
2.548
97.8
Sample Weight
4:45 pm
4986g. Gmb 2.553 Date: 2/15/96 Time:
Sample 3
Height
Gmb(est)
Gmb(corr)
%Gmm
N ini
124.0
2.275
2.287
87.8
N des
112.4
2.510
2.523
96.9
N max
111.1
2.539
2.553
98.0
Sample Weight
8:27 am
5027g. Gmb 2.550 Date: 2/22/96 Time:
Average
Height
Gmb(est)
Gmb(corr)
%Gmm
N ini
125.7
2.263
2.278
87.4
N des
113.7
2.502
2.519
96.7
N max
112.3
2.533
2.550
97.9
Figure 2-1. Sample Calc %Gmm Table
