Clean the washer with a degreasing cleaner and clean rag.
✓
Set the washer aside.
✓
With a degreasing cleaner and a clean rag, clean the area inside
the unit that contained the turntable, bearing, and washer.
✓
Carefully insert the turntable into the cavity.
✓
Using three 8/32 x 3/4" flathead screws, screw the turntable to
the unit.
✓
Reinstall the clean retainer. Tighten the six 4-40 x 1/4" flathead
screws in a crisscross pattern.
NOTE
When compacting at angles less than 0.7°, apply a light
lubricant such as Slick 50 One Lube to the turntable
before compacting each specimen.
If the user wants to compact specimens at an angle greater than 0.7°
after the unit is set up for an angle less than 0.7°, then perform the
following:
✓
Remove the six 4-40 x 1/4" flathead screws that attach the
retaining ring to the unit.
✓
Clean the retaining ring with a degreasing cleaner and clean rag.
✓
Remove the three 8/32 x 3/4" flathead screws that attach the
turntable to the unit.
✓
Insert a small screwdriver into one of the three holes in the
turntable and lift it up.
✓
Clean the turntable with a degreasing cleaner and a clean rag.
✓
Install a clean washer.
✓
Generously coat the top of the washer with Magnalube-G.
