Install the greased 100-mm loading head onto the interface
plate. Secure the 100-mm loading head to the mounting plate
with the eight small screws without washers (supplied with the
100-mm kit).
✓
Ensure that the 100-mm loading head slides freely from side to
side.
✓
To change the mold size stored in the control unit, press
〈SELECT〉.
✓
Recalibrate the specimen height (see page 3-6).
✓
If desired, recalibrate the angle of gyration (see page 3-8). If
you do not recalibrate the angle of gyration, it will be about 0.6°
higher than the angle set for the 150-mm mold.
The compactor can now be used to produce 100-mm asphalt
specimens. To use the 150-mm mold again, repeat the procedure
above, but replace the 100-mm loading head with the 150-mm
loading head and set the mold size to 150-mm. Note that the
150-mm loading head has washers under the eight small screws that
secure the loading head. Remember to recalibrate the angle of
gyration and the height after changing the mold size.
