Troxler ICO 4740 - Electrical Specifications

C-4
ELECTRICAL SPECIFICATIONS
Power sources
120/240 VAC
Peak power consumption
6000 VA/7200 VA
Current
25 A/30 A
Plug (detached)
NEMA 6-30
Length of power cord
1.8 m (6 ft)
Liquid crystal display
4 line x 20 character
Keypad
25-key sealed membrane
RS-232C configuration
Data Terminal Equipment
(DTE)
Serial data format
8 data bits, 2 stop bits, no
parity
Baud rate range
600 to 9600 baud
Maximum length of serial cable
3 m (10 ft)
Oven to PC-Compatible Computer Cable:
9-pin FEMALE 9-pin FEMALE
Rx (pin 2)
Tx (pin 3)
Tx (pin 3)
Rx (pin 2)
DTR (pin 4)
DSR (pin 6)
DSR (pin 6)
DTR (pin 4)
RTS (pin 7)
CTS (pin 8)
CTS (pin 8)
RTS (pin 7)
GND (pin 5)
GND (pin 5)
