ICO 3-3
• The ambient temperature should be between 10 and 50
°C (50 and 122 °F), and the relative humidity should be
less than 92%.
OVEN INSTALLATION
The oven requires no operator assembly. To install the oven,
follow the steps below:
CAUTION
Troxler has optimized the airflow in the oven to ensure
efficient combustion. Do not attach the exhaust duct
directly to a central exhaust unit. An increase in suction
due to external exhaust fans can affect the oven
performance.
1. Following the site selection guidelines on the previous
page, set the oven in place.
2. Using the adjustable feet, level the oven from front to
back and from side to side.
3. Remove all packaging material from the oven chamber,
including the pads under the rails.
4. Unpack the hearth plate and place it in the center of the
oven chamber resting on the 4 posts. Ensure that the
hearth plate does not touch the sides of the chamber.
5. Position the circuit breaker/power switch, found in the
lower left of the oven rear panel (see Figure 1) to the
OFF (down) position.
6. Connect the oven exhaust system as described in the
following section.
7. Connect the oven to the required power source (refer to
Appendix C).
