TSC TTP-244 Plus

20
TTP-244 Plus Bar Code
Printer Service Manual
14. Replace the DC motor and pull out the cables in connector JP 37.
Note: The colors of DC motor wires in connector JP 37 are yellow (outside) and green
(inside).
15. Reassemble the removed parts in the reverse order of the removal.
Screws
Cable tie
