19
TTP-244 Plus Bar Code
Printer Service Manual
11. Remove the one screw.
12. Remove the three screws on DC motor fixture.
13. Remove the three screws used to fix DC motor on the fixture and remove the cable tie.
Screw
DC Motor
fixture
Screws
