A-3
APPENDIX REPLACING OVEN COMPONENTS
Figure
Reference #
Item Description Item Part Number Fastener Description Fastener Part Number(s)
1 Badge, Logo, Encore/Encore 2 ENC-1192 Nut, Push, 1/8” 101293 (qty 2)
2 Catalytic Converter, Vent Tube RWD-9191 None None
3 Cover, Exhaust Tube ENC-1080 Screw, #8 x 3/8, Ph Mod Truss Hd, Cres 101682 (qty 6)
4 Cover, Left Side, Black ENC-1332-T010
Screw, #8-32 x 3/8, PPHD, Bk Oxide
Screw, #8 x 1/2, Security, Torx Hd, Bk Oxide
102922 (qty 1)
102756 (qty 1)
5 Cover, Right Side, Black ENC-1333-T010
Screw, #8-32 x 3/8, Security, Torx Hd, Bk Oxide
Screw, #8 x 1/2, Security, Torx Hd, Bk Oxide
102751 (qty 1)
102756 (qty 1)
6 Cover, Top, Black ENC-1331-T010 None None
7 Filter, Air ENC-1114 None None
8 Filter Bracket ENC-1389 Screw, #8 x 1/2, Serr Ph Truss Hd, Sheet Mtl 101688 (qty 6)
9 Housing, Exhaust Tube ENC-1294 Screw, #8 x 1/2, Serr Ph Truss Hd, Sheet Mtl 101688 (qty 6)
10 Leg, Plastic, Black (x4) HHB-3205 None None
11 Lower Front Panel ENC-1103-T001 None None
12 Pad, Abrasive, Non-Slip (x4) NGC-1187 None None
13 Panel, Rear ENC-1334 Screw, #8 x 1/2, Serr Ph Truss Hd, Sheet Mtl 101688 (qty 5)
14 Rack, Oven
ENC-1216 (SWY)
ENC-1279 (GM)
ENC-1406 (DNK)
None None
15 Stone, Baking ENC-3012 None None
To Next Page
