38
8.2.5 Ex.Mode – Rate of steam discharge during the exhaust stage
This parameter sets the rate at which steam is discharged during
the exhaust stage.
Access Code - 13
Resolution - 1
Value - 1 or 4
Fast Exhaust = 1
Slow Exhaust = 4
Cycle
1 2 3 4 5 6
Default
Values
Value
1 1 1 1 1 1
8.2.6 End Temp – Cycle End Temperature
This parameter sets the finish temperature of the exhaust stage.
The unit will signal a Cycle End only when the exhaust timer
has reached zero and the unit is below the End Temp. This also
indicates the proper time to open the door and unload the
chamber.
Access Code - 13
Resolution - 1ºF
Minimum Value - 104ºF
Maximum value - 280ºF
Cycle
1 2 3 4 5 6
Default
Values
Value
273 273 250 273 273 280
8.2.7 Puls num
.–
No. of vacuum pulses in the prevacuum stage
This parameter sets the number of vacuum pulses during the
prevacuum stage.
Access Code - 13
Resolution - 1
Minimum Value - 1
Maximum Value - 7
Cycle
1 2 3 4 5 6
Default
Value
Value
2 4 4 4 4 1
