Tuttnauer 3170 - Electrical Data; Specifications

Page 10 of 58 Pages
3.5 Electrical Data:
2540 3150 3170 3850 3870 5050 5075

Ampere (A) at 1Ph/230V/50/60 Hz
10.4
14.3
14.3
26 26 39 39
Ampere (A) at 3Ph/380V/50/60 Hz
  
8.7 8.7 13.0 13.0
Ampere (A) at 3Ph/230V/50/60 Hz
  
17 17 23 23
Ampere (A) at 3Ph/208V/50/60 Hz
  
17 17 23 23
Watts (W) 2400 3300 3300 6000 6000 9000 9000
Protection against electrical shock Class I
Models 3850/70, 5050/75 are equipped with a switching box for 1 or 2 h to 3Ph
3.6 Specifications
3.6.1 Dimensions
DIMENSIONS
MODEL
2540 3150 3170 3850 3870 5050 5075
Chamber diameter in mm. 250 310 310 380 380 500 500
Chamber depth in mm. 400 550 730 480 680 520 750
Chamber volume (lit.) 23 40 59 65 85 110 160
Overall
dimensions
Height (mm) 665 780 960 760 960 770 1000
Width (mm) 500 580 580 650 650 700 700
Length (mm.) 335 420 420 500 500 880 880
3.6.2 Technical Data
PROPERTY
MODEL
2540 3150 3170 3850 3870 5050 5075
Chamber material
St. St.
316 Ti
(1.4571)
St. St.
316 Ti
(1.4571)
St. St.
316 Ti
(1.4571)
St. St.
316 Ti
(1.4571)
St. St.
316 Ti
(1.4571)
St. St.
316 Ti
(1.4571)
St. St.
316 Ti
(1.4571)
Door material
ST.ST.
304L
ST.ST.
304L
ST.ST.
304L
ST.ST.
304L
ST.ST.
304L
St. St.
316 Ti
(1.4571)
St. St.
316 Ti
(1.4571)
Air supply pressure
to be regulated (Bar)
3-8 3-8 3-8 3-8 3-8 3-8 3-8
Feed water pressure
To be regulated (Bar)
2-3 2-3 2-3 2-3 2-3 2-3 2-3
Net weight (kg)
48 45 53 85 100 171 190
Shipping volume (m
3
)
0.21 0.56 0.56 0.56 0.56 1.35 1.35
Shipping weight (kg)
57 85 93 101 116 204 223
Chamber insulation
-
Fiber glass with reinforced material
Outer Cabinet - Stainless Steel
